Name: STDB-96-12 1200 Degree 5 Sides Glass Chamber Refractory Melting Furnace
Brand: STDB-96-12 1200 Degree 5 Sides Glass Chamber Refractory Melting Furnace
SKU: STDB-96-12
Rating: 4.7 (141 reviews)

Caratteristiche Galleria Descrizione di prodotto Richieda una citazione

Caratteristiche

Specificazioni

Classification: Laboratory Heating Equipments

Model Number: STDB-96-12

Product name: 1200 Degree Refractory Glass Sintering Furnace with peep door

Type: Benchtop

Max temperature: 1200â„ƒ

Continuous temperature: 1100â„ƒ

Power supply: AC:220V 50Hz 2.5KW

Heating element: Electric Resistance Wire

Temperature accuracy: Â±1â„ƒ

Thermocouple: N type

Certificazione: ISO9001; SGS; CE

Warranty: 1 Year

Informazioni di base

Certificazione: ISO9001; SGS; CE

Model Number: STDB-96-12

Termini di pagamento e spedizione

Packaging Details: 1.The furnace body was warped with enrivonmental plastic stretch film, then fixed well on the fumigation-free pallet 2.Tailored polywood case, coupled perfectly with the pallet 3.Filled with polyfoam between the furnace body and the case in all sides 4.Eas

Supply Ability: 1000 Set/Sets per Year

Descrizione di prodotto

Product Description

1200 Degree 5 sides Refractory Chamber Glass Melting Furnace

Model	STDB-96-12	STDB-288-12	STDB-640-12	STDB-1200-12	STDB-2160-12	STDB-3000-12	Customized
Chamber size(WxLxH)mm	400x600x400	600x800x600	800x1000x800	1000x1200x1000	1200x1500x1200	1500x2000x1000	Any size
Type	glass melting Furnace
Furnace structure	Chamber material, temperature controller system, heating element, furnace shell and other assistant parts
Max temperature	1200℃
Continue Operating Temp.	1150℃
Power supply	380V	380V	380V	380V	380V	380V	380V
Heating element	High quality alloy resistance wire
Chamber material	High temperature polycrystal alumina ceramic fiber material
Temperature precision	±1℃
Thermocouple	N type
Temperature controller	YUDIAN intelligent microcomputer PID controller can program 30 segments
Electronic component	DELIXI make
Heating rate	≤ 25℃/min ( suggest 15℃/min for longer life using of furnace )
Safety protection	Overheat and thermocouple-break alarm
Certification	ISO9001 CE SGS
Furnace shell	high quality cold-rolled steel sheets CNC processing
Insulation	High quality thermal insulation material to ensure a good uniformity
Accessories	One pair of high temperature furnace gloves
	One piece of crucible steel tong - One pair of crucible steel tongs
Optional	Paperless recorder
	Stainless steel exhaust chimney
	Alumina crucible
	Electric lifting structure

Applications:

1200℃ STDB Series products are mainly applied for the heat treatment of samples under vacuum or protective atmosphere, high quality chamber materials and stable temperature control system ensure the reliability of experimental data.The product uses the new-type ceramic fiber material as the furnace chamber material; the furnace tube material is fine, and the tube is sealed by stainless steel flanges on its both ends, the furnace can be work under the vacuum, there are air inlet and air outlet on the flange, also it can be filled in protective air, the precision needle-valve may adjust the air inlet flow rate.
